Laptop Specification Table
| Brand | Asus |
| Laptop Series | ExpertBook |
| Model | Asus ExpertBook P5 P5405CSA |
| User Segment | Business |
| Part No | P5405CSA-NZ0660 |
| Processor Brand | Intel |
| Processor Type. | Core Ultra 5 |
| Generation | Ultra |
| Processor Model | Core Ultra 5 226V |
| Processor Base Frequency | Not Applicable |
| Performance-Core Base Frequency | 2.10GHz |
| Low Power Efficient-Core Base Frequency | 2.10GHz |
| Processor Max Turbo Frequency | 4.50GHz |
| Performance-Core Max Turbo Frequency | 4.50GHz |
| Low Power Efficient-Core Max Turbo Frequency | 3.50GHz |
| Processor Core | 8 Cores |
| Performance-Cores | 4 |
| Low Power Efficient-Cores | 4 |
| Processor Thread | 8 |
| CPU Cache | 8MB |
| NPU | Yes |
| Neural Processing Unit (NPU) | Intel AI Boost |
| NPU TOPS | 40 |
| Chipset. | Integrated |
| RAM | 16GB |
| RAM Type | LPDDR5x |
| RAM Bus | 8533 MHz |
| Empty/Expansion RAM Slot | Unmentioned |
| Max. RAM Support | Unmentioned |
| Storage | 1TB SSD |
| Installed HDD Type | No HDD |
| HDD RPM | No HDD |
| HDD Expansion Slot | No |
| Installed SSD Type | NVMe PCIe |
| Installed SSD Generation | Gen 4 |
| M.2/SSD Expansion Slot | 1 |
| Storage Upgrade | Additional SSD Can be added |
| Graphics Chipset | Intel Arc 130V Graphics |
| Graphics Memory Accessibility | Integrated |
| Graphics Memory | Shared |
| Graphics Memory Type | Not Applicable |
| Display Size | 14 |
| Display Type | 2.5K QHD+ WQXGA Display |
| Panel Type | WV |
| Display Resolution | 2560x1600 |
| Coating Technology | Anti-Glare |
| Touch Screen | No |
| Display Refresh Rate | 144 Hz |
| Display Bezel | Slim Bezel |
| Brightness | 400nits |
| Display Features | 16:10, LED Backlit, sRGB: 100%, Screen-to-body ratio: 90 %, View angle(H/V): 178/178 Degree, Response time(Typ/Max) (ms): 25/30, Contrast (Typ): 1200:1 |
| Secondary Screen Size | No Secondary Screen |
| Secondary Screen Technology | No Secondary Screen |
| Secondary Screen Resolution | No Secondary Screen |
| Optical Drive | No |
| USB 3 Port | 2x USB 3.2 Gen 2 Type-A |
| USB C / Thunderbolt Port | 2x Thunderbolt 4, compliant with USB 4, supports display and power delivery |
| HDMI Port | 1 |
| Micro HDMI Port | No |
| Mini HDMI Port | No |
| Display Port, | No |
| Mini DP Port | No |
| VGA/D-Sub | No |
| Headphone & Microphone Port | Combo |
| Security Lock Slot | Kensington Nano Security Slot |
| LAN | No |
| WiFi | Wi-Fi 6E (802.11ax) (Dual band) 2x2 |
| Bluetooth | Bluetooth 5.3 |
| Audio Properties | Dolby Atmos Smart Amp Technology |
| Speaker | Yes |
| Microphone | Yes |
| WebCam | IR WebCam |
| Keyboard Layout | Backlit 1.5mm Key-travel, Spill-resistant Keyboard |
| Keyboard Back-lit | Yes |
| Num Key pad | No |
| Pointing Device | Touchpad |
| Fingerprint Sensor | Yes |
| Face Detection | Yes |
| TPM | Yes |
| Security Chip | Trusted Platform Module (TPM) 2.0 |
| Operating System | Free-Dos |
| Licensed Application | No |
| Body Material | Aluminum |
| Color | Misty Grey |
| Dimensions | 312.0 x 223.2 x 14.9mm |
| Weight | 1.23 kg |
| Battery | 3 Cell |
| Battery Capacity | 63WHrs |
| Battery Type | Li-ion |
| Backup Time | Up to 3.5 Hrs. |
| Power Adapter | 65W |
| Adapter Type | AC Adapter |
| Warranty Details | 3 Year International (3 year for Battery and Adapter) |
| Warranty Claim Duration (Approximate) | Estimated Warranty Claim Duration 20 Days. It may take additional time up to 40 days |
| Certifications | US MIL-STD 810H military-grade standard, EPEAT Gold with Climate+, Energy star 8.0, FSC Recycled, REACH, RoHS, TCO Certified |
| Specialty | Fingerprint sensor integrated with Power Key, IR webcam with Windows Hello support, BIOS Booting User Password Protection, BIOS Integrity Measurement Support, BIOS Self Recovery, CSME BIOS Redundancy Assistance, HDD User Password Protection and Security, Intel CSME Firmware Resilience, Intel BIOS Guard, Intel Boot Guard, Microsoft Pluton Security Processor, Microsoft Security Level 3, Support Absolute Persistence 2.0 (Computrace). System diagnosis, Battery health charging, Fan Profile, Splendid, Tru2Life, Function key lock, WiFi SmartConnect, AppDeals. |
| Others | 1080p FHD camera with IR function to support Windows Hello With privacy shutter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal. |
| Country Of Origin | Taiwan |
| Made in/ Assemble | China |
| Disclaimer | Mentioned Battery Backup information is collected from manufacturer. As per manufacturer the backup time may very for different use case, settings, applications and some other factors. Dual channel RAM required For Intel Arc Graphics. |
